140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

Brand Name : SKF

Model Number : H3032

Certification : ISO9001:2008

Place of Origin : Sweden

MOQ : 1 pcs

Price : negotiation

Payment Terms : T/T or western Union or PayPal

Supply Ability : 3,000pcs per month

Delivery Time : 3 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with wooden case for outer packing

Product Name : H3032

Shaft diameter : 140 mm

OD : 160 mm

Width : 93 mm

Material : Gcr15

Type : Metric series adapter sleeve

Lubrication : oil or grease

Lead time : within 3 days

Contact Now

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

1. Specification:

Bearing No.	H3032
Type	Adapter sleeve
ID	140 mm
OD	160 mm
Height	93 mm

2. Feature:

(1) Single row

(2) With locking nut

(3) chrome steel material

(4) Sweden origin

(5) Competitive price

(6) Fast delivery

3. Bearing Picture:

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

4. We also supply following adapter sleeves:

Dimensions			Abutment dimensions				Designations
d1(mm)	D(mm)	B(mm)	da Max	db Min	Ba Min	Mass(kg)	Designations	Adapter sleeve
17	47	14	28,5	23	5	0,16	1204 EKTN9	H 204
20	52	15	33	28	5	0,21	1205 EKTN9	H 205
20	52	18	31	28	5	0,23	2205 E-2RS1KTN9	H 305E
20	52	18	32	28	5	0,23	2205 EKTN9	H 305
20	62	24	35,5	29	5	0,42	2305 EKTN9	H 2305
25	62	16	40	33	5	0,32	1206 EKTN93)	H 206
25	62	20	36,5	33	5	0,36	2206 E-2RS1KTN9	H 306E
25	62	20	38	33	5	0,36	2206 EKTN9	H 306
25	72	27	40	35	5	0,62	2306 E-2RS1KTN9	H 2306
30	72	17	47	38	5	0,44	1207 EKTN93)	H 207
30	72	23	42,5	39	5	0,55	2207 E-2RS1KTN9	H 307E
30	72	23	45	39	5	0,54	2207 EKTN9	H 307
30	80	31	43,5	40	5	0,86	2307 E-2RS1KTN9	H 2307E
30	80	31	46	40	5	0,84	2307 EKTN9	H 2307
35	80	18	53	43	6	0,58	1208 EKTN93)	H 208
35	80	23	49	44	6	0,67	2208 E-2RS1KTN9	H 308E
35	90	23	61	44	6	0,85	1308 EKTN9	H 308
35	90	33	55	45	6	1,2	2308 E-2RS1KTN9	H 2308
40	85	19	57	48	6	0,68	1209 EKTN93)	H 209
40	85	23	53	50	8	0,76	2209 E-2RS1KTN9	H 309E
40	85	23	55	50	8	0,78	2209 EKTN9	H 309
40	100	36	60	50	6	1,4	2309 EKTN9	H 2309
45	90	20	62	53	6	0,77	1210 EKTN93)	H 210
45	90	23	58	55	10	0,84	2210 E-2RS1KTN9	H 310E
45	110	27	70	55	6	1,45	1310 EKTN9	H 310
45	110	40	65	56	6	1,9	2310K	H 2310
50	100	21	70	60	7	0,99	1211 EKTN93)	H 211
50	100	25	65,5	60	11	1,1	2211 E-2RS1KTN9	H 311E
50	100	25	67	60	11	1,15	2211 EKTN9	H 311
50	120	43	72	61	7	2,4	2311K	H 2311

If you want to buy this bearing,just send email directly to tommy@gqbearing.com
